Yamaha DHR15 powered loudspeaker features a rugged wooden cabinet, 1000 watts of Class D power and DSP to produce up to 131dB SPL with remarkable clarity, offering an ideal solution for anyone ready to step up their sound reinforcement game to a new level of professional quality, accuracy and performance. A premium plywood cabinet finished in a tough polyurea coating provides durability not found on other loudspeakers in this class.
DHR15 is optimized for FOH applications and features custom transducers driven by a DSP-equipped class-D power amplifier to deliver stunning sound quality and clarity. A flexible 2-channel mixer allows for multiple sources and connection types. Rigging points are also provided for suspended applications. Isn't it time you audition DHR quality and performance to improve your sound?
- 15" powered loudspeaker with 1000W of Class D power
- DHR15 achieves class-leading SPL with stunning clarity throughout its frequency response range
- Equipped with a 1.4" HF compression driver and high-output 15"" LF unit for accurate vocal reproduction and outstanding bass response
- Maximum 131dB SPL of power and wide frequency response range of 44Hz-20kHz
- Ultra-precise 48-bit DSP processing for clear high-definition sound and built-in D-Contour intelligent dynamic control
- Durable plywood enclosure delivering outstanding acoustic performance
- Dual pole sockets to allow straight 0° placement or a 7° downtilt to cover your audience's needs
High-efficiency 1000W Class D amplifier
DHR15's lightweight, high performance Class-D amplifier is capable of producing up to 1000W of power, achieving an SPL of 131dB delivered with remarkable clarity and dynamic characteristics.
Custom-designed transducers
The high power output woofer delivers well-defined, powerful bass with minimal distortion, while the 1.4" precision compression driver produces accurate midrange and high frequencies.
A rugged, highly portable cabinet
DHR15 features a plywood enclosure like Yamaha's acclaimed DZR loudspeakers to deliver outstanding durability and acoustic performance.
Dual-angle pole mount socket
DHR15's pole mount socket offers two positions – 0° and 7° – to direct acoustic energy away from reflective surfaces in a room with low ceilings and onto your audience where it belongs.
Easy-to-use onboard 2-channel mixer
DHR15 has two input channels. CH1 has a combo jack which accepts either XLR or 1/4" TRS at mic or line level. CH2 offers two input options: a combo jack that accepts XLR or 1/4" TRS, and a pair of RCA connectors for input from CD players or other stereo line-level sources. The onboard mixer allows you to select either CH1+2 MIX to mix the signal of CH1 and CH2, or CH1 THRU to pass the signal from CH1 only.
| SKU | YAM-DHR15 |
| Vendor | Yamaha |
| Active Passive | Active |
| Included From Manufacturer | Power cord |
| MPN | DHR15 |
| Product Unique Features | Dual pole sockets to allow straight 0° placement or a 7° downtilt |
| Speaker Application | Full-Range |
| Speaker Size Filterable | 15 |
| Connectors | 2 × XLR / 1/4" combo inputs Stereo RCA input XLR output |
| Covering Material | Polyurea |
| Enclosure Material | Plywood |
| Equalization (EQ) | D-CONTOUR switch HPF switch |
| Frequency Range | 44 Hz - 20 kHz |
| Pole Mount | Yes |
| Power | 1,000 watts |
| Product Weight | 52.9 lb |
| Protection Circuit | Yes |
| Tweeter/Horn | 1.4" diaphragm 1" throat compression driver Ferrite magnet |
| Width | 17" |
| Depth | 15.9" |
| Height | 27.2" |
| Woofer/Low Frequency | 15" cone 2.5" voice coil Ferrite magnet |
