The MG10XU offers 4 XLR channels with 3 band EQ, two of which feature 1-Knob Compression, as well as 4 mono and 3 stereo line inputs. In addition to balanced main and headphone outputs, MG10 also features Monitor and Aux(FX) Send outputs for added flexibility. Add to all of this a 24-bit USB Audio Interface and the powerful SPX Digital Multi Effect Processor, and the MG10XU is a perfect mixer for practice spaces, acoustic venues, and of coarse the electronic musician or keyboard player who deserves total control to mix their many components.
Optimized Steel Chassis
Starting with the chassis, you will see that quality is the heart of the matter. The steel powder-coated and impact resistant chassis offers a compact and contoured design, which optimizes the way heat is moved away from the components to lower operating temperatures. In this new layout the power supply is separated from analog circuit to reduce noise, which also extends the life of internal components. This all protects the upgraded glass-substrate circuit board, which increases flexibility, protecting circuit integrity under stress.
D-PRE Preamps
The preamp is where sound creation begins, and ultimately determines the character and quality of your overall mix. The importance of this critical first step inspired Yamaha to develop the most fat and warm sounding preamps possible-their newly refined D-PRE mic preamps. Initially intended for use with Yamaha's high-end recording gear, these studio-grade, discrete Class-A mic preamps employ an inverted Darlington circuit design that features multiple circuitry elements in a multi-layered configuration in order to deliver more power with lower impedance. This means all the character, depth and feel of your original signal will be delivered with fat, natural sounding bass and smooth, soaring highs. Rediscover a favorite mic or trusted instrument by capturing the full range of your musical expression with sound that you don't hear, so much as feel. With 48V phantom power for each channel and a sound that is incomparable in a compact mixer today, these studio-grade discrete Class-A mic preamps set the MGP apart, clearly defining a class all its own.
Capture the Performance
Not only is a download code for Cubase AI included with the MG Series, but this is a 24-bit/192kHZ USB audio Class 2.0 compliant, 2 in and 2 out audio interface, ensuring the performance is captured in pristine digital quality. As an added bonus, MG mixers are compatible with camera connection kit or lightning to USB camera adapter for playback and recording with your favorite iOS devices.
1-Knob Compressors
Originally a Yamaha innovation, 1-knob compression is now a popular feature on an increasing number of compact mixing consoles with good reason. These intelligent compressors add optimally set compression to a wide variety of input sources with the touch of a single control-minus the hassle of setting up and configuring complex outboard gear. The MG features Yamaha's newly upgraded 1-knob compressors that feature LED indicators allowing you to visually monitor when the compression "kicks in" on each channel.
More SPX Effect Presets
While previous MG mixers offered 16 SPX presets, Yamaha has added 8 new presets, including Delay, Symphonic LFO, Tremolo LFO, Early Reference, Gate Reverb, Radio Voice, and Pitch Change. With this wide array of presets to choose from, creatively tailoring the perfect mix has never been so easy or fun.
SKU | YAM-MG10XUPP |
Vendor | Yamaha |
Audio Recording | Stereo over USB |
Connectivity | USB |
Included From Manufacturer | Power Cable |
Mic Preamps | 4 |
Mixer Channel Filterable | 10 |
Mixer Type | Analog |
MPN | MG10XU |
Product Unique Features |
D-PRE Preamps 1-Knob Compression SPX Effect Processor 2 in, 2 out 24-bit/192kHz USB Audio Interface |
Simultaneous Inputs | 7 |
Aux/Effect Sends | Aux(FX) Send: (1) 1/4 |
Channel EQ | 3-band (Ch. 1-4) |
Effects | 24 SPX Presets |
Number of Faders | Knobs |
Audio Inputs | 4 XLR Microphone 4 Mono + 2 Stereo Line |
Audio Outputs | Main: (2) 1/4", (2) XLR Bal Headphones: (1) 1/4" Monitor: (1) 1/4 |
Phantom Power | 4 Channels, 48V |
Product Weight | 4.2 lbs. |
Rackmountable | No |
Width | 9.6" |
Depth | 11.57" |
Height | 2.79" |
Yamaha Live Sound Products Limited Warranty
Thank you for selecting a Yamaha product. Yamaha products are designed and manufactured to provide a high level of defect-free performance. Yamaha Corporation of America ('Yamaha') is proud of the experience and craftsmanship that goes into each and every Yamaha product. Yamaha sells its products through a network of reputable, specially authorized dealers and is pleased to offer you, the Original Owner, the following Limited Warranty, which applies only to products that have been (1) directly purchased from Yamaha's authorized dealers in the fifty states of the USA and District of Columbia (the 'Warranted Area') and (2) used exclusively in the Warranted Area. Yamaha suggests that you read the Limited Warranty thoroughly, and invites you to contact your authorized Yamaha dealer or Yamaha Customer Service if you have any questions.
This warranty covers the listed products against defects in materials or workmanship for the following periods:
- DBR series powered loudspeakers: seven (7) years
- DSR series powered loudspeakers: seven (7) years
- DXR series powered loudspeakers: seven (7) years
- DXS series powered subwoofers: seven (7) years
- BR series passive loudspeakers: three (3) years
- CBR series passive loudspeakers: three (3) years
- Club series passive loudspeakers: three (3) years
- P series power amplifiers: three (3) years
- MSR series powered loudspeakers: three (3) years
- MG series mixers: one (1) year
- EMX series powered mixers: one (1) year
- STAGEPAS series PA system: one (1) year
- SPX/Q signal processors: one (1) year
- Loudspeaker accessories: one (1) year
- Other Yamaha live sound products: one (1) year
Yamaha will, at its option, repair or replace the product covered by this warranty if it becomes defective, malfunctions or otherwise fails to conform with this warranty under normal use and service during the term of this warranty, without charge for labor or materials. Repairs may be performed using new or refurbished parts that meet or exceed Yamaha specifications for new parts. If Yamaha elects to replace the product, the replacement may be a reconditioned unit. You will be responsible for any installation or removal charges and for any initial shipping charges if the product(s) must be shipped for warranty service. However, Yamaha will pay the return shipping charges to any destination within the USA if the repairs are covered by the warranty.
This warranty does not cover (a) damage, deterioration or malfunction resulting from accident, negligence, misuse, abuse, improper installation or operation or failure to follow instructions according to the Owner's Manual for this product; any shipment of the product (claims must be presented to the carrier); repair or attempted repair by anyone other than Yamaha or an authorized Yamaha Service Center; (b) any unit which has been altered or on which the serial number has been defaced, modified or removed; (c) normal wear and any periodic maintenance; (d) deterioration due to perspiration, corrosive atmosphere or other external causes such as extremes in temperature or humidity; (e) damages attributable to power line surge or related electrical abnormalities, lightning damage or acts of God; or (f) RFI/EMI (Interference/noise) caused by improper grounding or the improper use of either certified or uncertified equipment, if applicable.
Any evidence of alteration, erasing or forgery of proof-of-purchase documents will cause this warranty to be void. This warranty covers only the Original Owner and is not transferable.
Warranty service will only be provided for defective products within the Warranted Area. Contact your local authorized Yamaha dealer who will advise you of the procedures to be followed. If this is not successful, contact Yamaha directly. Yamaha may request that you send the defective product to a local authorized Yamaha Servicer or authorize return of the defective product to Yamaha for repair. If you are uncertain as to whether a dealer has been authorized by Yamaha, please contact Yamaha's Service Department or check Yamaha's website.
Product(s) shipped for service should be packed securely and must be accompanied by a detailed explanation of the problem(s) requiring service, together with the original or a machine reproduction of the bill of sale or other dated, proof-of-purchase document describing the product, as evidence of warranty coverage. Should any product submitted for warranty service be found ineligible therefore, an estimate of repair cost will be furnished and the repair will be accomplished only if requested by you and upon receipt of payment or acceptable arrangement for payment.
Any implied warranties, including warranties of merchantability and fitness for a particular purpose shall be limited in duration to the applicable period of time set forth above. Yamaha shall not be responsible for incidental or consequential damages or for damages based upon inconvenience, loss of use, damage to any other equipment or other items at the site of use or interruption of performances or any consequences. Yamaha's liability for any defective product is limited to repair or replacement of the product, at Yamaha's option.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This Warranty gives you specific legal rights, and you may also have other rights which vary from state to state. This is the only express warranty applicable to the product specified herein; Yamaha neither assumes nor authorizes anyone to assume for it any other express warranty.
