Yamaha MODX+ has more sounds, more control and more synth to help you stand out on stage, in the studio or on stream. MODX7+ is a compact, lightweight, 76-key synthesizer with all the sounds, splits, zones and layers keyboardists need – all powered by the same innovative technologies found in Yamaha's flagship Montage, including the AWM2 sample and synthesis engine and the FM-X synth engine. MODX+ Motion Control brings the sophisticated automation of music production to live performances by giving you simultaneous control of up to 128 parameters.
- Semi-weighted synth action provides expressive response in a 76-note keyboard
- AWM2 is a proprietary sampled-based subtractive synthesis technology
- FM-X features 8-operator FM synthesis capable of producing incredible dynamic sound
- Motion Control is a highly customizable synthesizer engine control matrix
- MODX OS adds Voices, Live Sets and other new features
- Virtual Circuitry Modeling recreates the sound and behavior of vintage effect and signal processors
- 1.75GB internal flash memory lets you install samples and external libraries for a completely personalized sound set
- 256-note total polyphony: 128-note stereo AWM2 + 128-note FM-X
- 4-part Seamless Sound Switching: change Performances while holding notes without sound or effect cutoff
- Motion Sequences are tempo-synchronized control sequences for creating rhythmic sound changes
Sound
The most important element of any instrument is the sound. MODX7+ makes all elements of your music sound amazing. MODX7+ uses the same technology that powers the flagship Montage: 128 notes of AWM2 (Advanced Wave Memory 2) sample and synthesis polyphony for stunning emulative acoustic instruments, synth sounds and drums. MODX7+ also features 128 notes of FM-X (Frequency Modulation) polyphony – a unique, expressive, highly-programmable synthesis technology for dynamic, electro-modern music creation.
Control
Every artist wants to find their own sound. Motion Control is designed to bring the sophisticated automation of music production to realtime live performances, all to help you create inspired music that stands out on every stage, studio or stream.
Mobility
Designed for musicians on the go and weighing in at just 16.3 pounds, MODX7+ is compact, lightweight and mobile.
AWM2
The AWM2 engine is exclusive to Yamaha synthesizers and offers much more than just sample playback. Each of the 16 AWM2 Parts feature 8 programmable synthesizers with 18 different filter types, amplitude, pitch and filter envelope generators, 9 LFOs, 3-band EQ and a dedicated dual insert effect with Virtual Circuitry Modeling.
FM-X
Everything you love about the iconic DX7 meets the latest Yamaha innovations. FM-X produces classic 80s or cutting-edge EDM synthesizer sound with incredible dynamic range, power and fidelity. MODX7+ goes well beyond the capabilities of the original DX7 with an 8-operator FM architecture, 128-note polyphony, many filter types and more – all with Motion Control for ever-evolving and changing textures to create sounds no one has ever heard before.
Smart Morph
Smart Morph enables morphing between FM-X sounds. Its sophisticated AI algorithm creates an interactive morphing map from up to eight FM-X sounds. You can then 'play' this map from the touchscreen or use the Super Knob to move between two points. The result is a staggering number of interesting and interactive new sounds.
256-note total polyphony
MODX7+ features 128-note stereo AWM2 polyphony and 128 notes of FM-X polyphony. Thanks to the unique architecture of MODX+ and Montage, this polyphony is always available without latency or compromising other features.
Effects
MODX7+ is packed with DSP innovation, power and sound quality to bring you everything from high-definition reverbs to detailed Virtual Circuit Modeling (VCM) effects. Get EDM sound with effects like Beat Repeat, Vinyl Break or Bit Crusher. Use the Spiralizer effect to create the auditory illusion of tone continuously rising or falling in pitch. Add a compressor with sidechain for a modern 'ducking' effect. Or go retro with vintage effects like Analog Delay, VCM Phaser or a variety of Amp Simulators. Piano players will feel like they're in heaven (or some other incredible performance space) with piano-focused effects like Damper Resonance and HD reverbs for a super-realistic piano experience.
A/D input
A stereo A/D input allows you to bring external sources like analog synthesizers, vocals and other instruments into the MODX7+ motion control system, which means MODX7+ control goes well beyond simple onboard effect processing. Control individual parameters with the physical controls or have MODX7+ provide 'invisible hands' using Motion Control. Add the Vocoder, Envelope Follower and Auto Beat Sync and it's like the A/D input on MODX7+ becomes an instrument unto itself.
Sidechain
Sidechain is a popular effect in modern dance music where a pad or other sustain part is keyed to the kick drum. When the kick drum plays, it ducks down the sustained part, creating a pumping rhythmic effect.
Share with Soundmondo
Soundmondo is a social sound sharing network that lets you store and recall MODX+ and Motage Performances and share them with other users. Each stored Performance can be rated, named and given a custom image from your photo library. The Soundmondo app for iOS lets you upload and download new Performances directly to MODX6s+ with an iOS device.
Patch compatibility
Out of the box, MODX7+ gives you access to sounds made by Yamaha's world-class sound designers and artists, including sounds from the Motif series as well as the legendary DX7 – you'll have a massive sound library at your fingertips! MODX7+ is directly compatible with Motif XS/XF Voices and Performances. The free online FM converter webapp makes it compatible with DX7, DX7II, TX802 and TX816 synthesizer content as well.
DAW Integration
MODX+ Connect is a convenient tool that lets you transfer data between your computer and MODX7+. Song data created on the MODX7+ can be transferred to your computer, and the Performance data edited on the MODX7+ can be saved as a file on the computer. MODX+ Connect works standalone or as a VST or AU plug-in, allowing you to save the edited settings of MODX7+ and use them for another project.
Multi-channel USB audio interface
As expected for modern computer-based music production, MODX7+ features a professional 4-in/10-out, multi-channel USB audio interface. Coupled with two A/D inputs, MODX7+ is a perfect centerpiece for any professional recording studio or live computer rig. A single-cable connection replaces the need for an external audio interface!
Rhythm Pattern
Drummer running late again? MODX+ Rhythm Pattern is like a built-in drum machine with easy access to thousands of patterns from a front panel button. Quickly add a rhythm when songwriting, practicing or waiting for the drummer to set up (or show up).
Super Knob
Super Knob is to shaping sound as a conductor is to an orchestra: it directs individual dynamic elements into a single musical expression. Like a conductor, the Super Knob can tell one player to turn up while another turns down. You can change the shape of notes from long to short, bright to dark or move a player from being right next to you to the back of the concert hall. Super Knob allows simultaneous control of up to 128 parameters in a single Performance. This means you can control mix functions like volume, pan and effect sends or detailed synth parameters like filters, LFOs and Operators. You can even control Super Knob with an expression pedal, making it easy to manipulate the sound even while playing with both hands.
Motion Sequence
Motion Sequences are tempo-synchronized, completely customizable control sequences that can be assigned to virtually any synthesizer parameter and provide incredible new ways of creating sound. Motion Sequences also have dedicated controls on the front panel, making it easy to manipulate and change in real-time, providing incredible interactivity and expression.
Envelope Follower
The Envelope Follower converts audio into a control source for control of virtually any synthesizer parameter. For example, a drum loop could drive effects parameters for a cool rhythm, or a vocal recording could control multiple parameters for a 'talking' synthesizer. The audio can even be a live source through the A/D input.
Audio Beat Sync
Audio Beat Sync (ABS) detects the beat of an external device like an electronic drum kit, drum machine or audio player plugged into the A/D input and synchronizes the MODX7+ Arpeggiator, Motion Sequencer or Songs to the tempo of the external input.
Rubber coated pitch bend and mod wheels
Just like the flagship Montage, MODX7+ has rubber-coated pitch and modulation wheels for a premium feel when performing.
| SKU | YAM-MODX7PLUS |
| Vendor | Yamaha |
| Aftertouch | No |
| Analog Digital | Digital |
| Built In Speakers | No |
| Included From Manufacturer | Power supply |
| Keys Weighted | Semi-Weighted |
| Number of Keys | 76 |
| Key Size | Full Size Keys |
| Midi | In, Out, and USB |
| Mono Poly | Polyphonic |
| MPN | MODX7+ |
| Product Unique Features |
Motion Control customizable synthesizer engine control matrix Virtual Circuitry Modeling recreates the sound and behavior of vintage effect and signal processors 4-part Seamless Sound Switching to change Performances without sound or effect cutoff |
| Arpeggiator | Yes |
| Control Connections | 1/4" sustain footswitch input 1/4" assignable footswitch input 2 × 1/4" expression pedal inputs |
| Onboard Controllers | Pitch bend wheel Modulation wheel 4 × multi-function control sliders 4 × multi-function control knobs Assignable, multi-parameter Super Knob with visual feedback |
| Effects | 12 × Reverb types 76 × Variation types 76 × Insertion (A, B) types 15 × Master Effect types 71 × A/D part insertion types 1st part EQ 2nd part EQ |
| Audio Inputs | Dual 1/4" stereo external audio input |
| Audio Outputs | Dual 1/4" stereo output 1/4" stereo headphone output |
| Internal Storage Capacity | 1.75GB |
| Key Action | Semi-weighted synth action |
| Multitimbral Capability | 16 parts |
| Product Weight | 16 lb 5 oz. |
| Programs/Presets | 1.75GB internal flash memory for samples and external libraries ±2,000 Performances 256 preset Live Sets 2,048 user Live Sets 10,000+ preset arpeggios 256 user arpeggios 128 Songs |
| Sequencer | 16 sequence tracks Tempo track Scene track |
| USB Flash Drive Port (to Device) | Program/Preset Storage;System Updates |
| USB Port (to Host) | MIDI;Audio;Editor/Librarian/Patch Manager |
| Voices of Polyphony | 256-note total polyphony: 128-note stereo AWM2 + 128-note FM-X |
| Width | 45" |
| Depth | 13" |
| Height | 5.3" |
