Studiologic Numa X Piano represents a real revolution for digital piano players. High end features, sounds and effects have been designed and organized to be controlled in an easy, intuitive and effective way to offer the best feeling in performance. Numa X Piano is the perfect combination of a top-quality musical instrument based on a new sound generation architecture with a four-zone MIDI controller derived from the renowned SL Line and addition of a four-track digital mixer and USB audio interface. It's a powerful setup for the studio and live gigs with a brand new user experience.
- UX Logic with adaptive color controls and Zoom function to quick edit zone parameters
- 8 sound banks with over 200 factory sounds
- Acoustic piano sounds with enhanced TRS technology and high-resolution spectral interpolation
- Electric piano sounds with physical modeling of vintage electrics and hybrids
- High-end Fatar hammer action keyboard
- 2 assignable expression sticks
- 4 zones assignable to internal sounds or external MIDI
- 4 mic/line audio inputs with 4-track digital mixer and dedicated effects
- Easy favorites storage and recall
- Global EQ: bass, mid, treble
- Deep effects section with two insert effects per zone plus master reverb and delay
- Audio over USB
UX Logic: a revolutionary and stylish user experience
UX Logic is the name of Studiologic's adaptive color user interface. The razor-sharp TFT color display and the color-coded adaptive encoders are always synchronized by zone, allowing you to navigate all realtime settings in an intuitive way, while Zoom mode lets you focus on a single zone's values. An 'uncrowded' control panel contributes to the elegant design of Numa X Piano, a pleasant side effect of such an effective and rational interface.
Powerful acoustic and electric physical modeling with HD effects
The sound engines are based on a powerful mix of sampling, waveshaping and real physical modeling. Acoustic modeling makes acoustic piano sounds even more real by reproducing string resonances, duplex scale, release note, key off and damper noise, while electric modeling implements a detailed physical model of a vintage electric piano. There are eight insert effects (2 for each zone) plus master reverb and delay. UX Logic Zoom settings are available to quickly tweak effects, which can be stored in each program.
Let your fingers go with the Fatar touch
Numa X Piano 73 features the Fatar hammer action TP/110 keybed with three contacts and aftertouch, a massive improvement over the TP/100 design with new hammers, sturdy keys and impressive bounce reduction. Aftertouch is triggered by the hammers for a more accurate control. Four velocity curves, a general sensitivity control and black/white balance let you dial in the perfect feel. TP/110 is also remarkably light for better portability.
Numa Manager for sound database expansion
A generous section of internal memory is left free for additional sounds to be published on the Studiologic website. Factory and user programs can be moved and reordered with the Numa Manager desktop app, also used for easy firmware updates.
Built-in digital mixer and USB audio interface
Numa X Piano also includes four audio inputs and a four-track digital mixer with gain and EQ controls, letting you mix and record external sources such as microphones, bass, guitars or other keyboards. Thanks to Numa X Piano's built-in USB audio interface, you can record directly to your computer or tablet with local direct control over audio levels.
Versatile connectivity
You may want a switch pedal, a continuous pedal or a triple pedal – why not all three at once, plus more? Four audio inputs, 5-pin DIN MIDI and USB for both MIDI and audio let you connect all your instruments and devices.
Assignable expression sticks
The aluminum expression sticks can control any desired sound parameter. Stick 1 is bi-directional and springed; Stick 2 is unidirectional and not springed.
SKU | STU-NUMAXPIANO73SE |
Vendor | Studiologic |
Built In Speakers | No |
Included From Manufacturer |
VFP1/10 sustain pedal Power supply |
Keys Weighted | Hammer Weighted |
Number of Keys | 73 |
Midi | In, Out, and USB |
MPN | AMS-NUMA-X-PIANO-73 |
Product Unique Features |
UX Logic with adaptive color controls and Zoom function to quick edit zone parameters 4 mic/line audio inputs with 4-track digital mixer and dedicated effects Audio over USB |
Accompaniments | No |
Control Connections | 1/4" footswitch input 1/4" expression pedal input 1/4" triple pedal input |
Onboard Controllers | Assignable bi-directional expression stick, springed Assignable unidirectional expression stick, not springed |
Effects | 8 × insert effects (2 per zone) Master reverb and delay |
Finish | Black |
Audio Inputs | 4 × 1/4" mic/line inputs Onboard 4-channel digital mixer with gain and EQ controls, dedicated effects |
Audio Outputs | Dual 1/4" stereo output 1/4" stereo headphone output |
Key Action | Fatar TP/110 premium hammer action with triple switch detection system and aftertouch |
Number of MIDI Control Zones | 4 |
Product Weight | 26 lb |
Programs/Presets | 200+ factory sounds 250 user programs |
Transpose Feature | Yes |
USB Port (to Host) | MIDI;Audio;System Updates;Editor/Librarian/Patch Manager |
Width | 41" |
Depth | 12" |
Height | 5" |
Every product from Studiologic by Fatar has been carefully manufactured, calibrated and tested, and is warranted to be free from defects in materials or workmanship for a period of two years from the date of purchase by the original owner. Please register your product to get full support. Damage caused by incorrect transport, mounting or handling is not covered by this warranty.
